Name: Welding positioners type SPK-BZ-D
Brand: KOVACO
SKU: SPK-BZ-D

SPK-BZ-D

Bearing capacity from 600kg to 5t

A double column single-axis positioner for long parts used in the applications not requiring a change of the working height. Even the basic configuration positioner features stepless adjustment of table rotation speed in the entire range and is equipped with a START-STOP system. Various optional features of the control system further expand the control capabilities of the positioner. In addition to manual operation, the positioner can be equipped with a system for axis measurement with position programming options.

A double column positioner for long parts
Single-axis positioner
Stepless table speed control with START-STOP
Anchoring required
Optional remote control
Optional foot switch for START-STOP
Optional customization of the clamping table to customer specification

Request a quote Back to welding positioners

Specifications

Technical parameters.

Type	SPK 6-BZ-D	SPK 12-BZ-D	SPK 25-BZ-D
Bearing Capacity (kg)	1,200	2,400	5,000
Table Torque (Nm)	1,120	3,810	10,640
Max. Table Torque (Nm)	1,530	5,440	15,200
Table Rotation Speed (rpm)	0.1 - 1.7	0.1 - 1.1	0.07 - 1.1
A (mm)	550	650	1,100
B (mm)	650	730	1,000
C (mm)	1,420	1,510	1,650
D (mm)	500	500	750
DS max. (mm)	3,000	3,000	6,000
P (mm)	900	900	1,100

Type	SPK 6-BZ	SPK 12-BZ	SPK 25-BZ
Bearing Capacity (lb)	2,646	5,291	11,023
Table Torque (lb-ft)	826	2,810	7,848
Max. Table Torque (lb-ft)	1,128	4,012	11,211
Table Rotation Speed (rpm)	0.1 - 1.7	0.1 - 1.1	0.07 - 1.1
A (in)	21.7	25.6	43.3
B (in)	25.6	28.7	39.4
C (in)	55.9	59.4	65.0
D (in)	19.7	19.7	29.5
DS max. (in)	118.1	118.1	236.2
P (in)	35.4	35.4	43.3

Welding positioners type SPK-BZ-D

Technical parameters.

Machine dimensions.
